PTFE insulated Twin Twisted IEC Exposed Junction Thermocouple with Miniature Plug - Type J - 300mm Length

Change Currency

SKU
XE-0429-001
£6.42 £5.35
  • Buy 2 - 4 for £5.65 £4.71 each
  • Buy 5+ for £5.14 £4.28 each
Series:
Exposed Junctions
Lead Time:
7 - 10 working days
Weight:
200g
Tariff Code:
90259000
Manufacturer:
Labfacility
Country of Manufacture:
GB
Product Compliance:
Postage & Delivery:

Thermocouple type K,J or T. Fast response, welded exposed junction available in Class 1 cable specification in accordance with BS EN 60584-3:2008 with a Miniature plug termination.

Ideal for test & development applications.

Specifications

General Description Fast response, welded exposed junction
Sensor Type Exposed Junction
Thermocouple Type J IEC
Cable Length 300mm
Cable Type Teflon® PTFE insulated twin-twisted lead
Core / Strands 1/0.2mm
Termination Type Miniature flat pin plug colour coded in accordance IEC 584
Max. Temperature 260°C
Min. Temperature -75°C
Tolerance Class 1
Standards Met IEC-584-3
Connector Type Plug
Connector Size Miniature
