Type J Glassfibre Insulated Flat Pair Cable / Wire with Stainless Steel Overbraid (BS)

Change Currency

SKU
WJ-247-D
£3.74 £3.12
Lead Time:
In-Stock, sold by the metre
Weight:
500g
Tariff Code:
90259000
Country of Manufacture:
GB
RoHS Compliant:
Product Compliance:
Postage & Delivery:

Type J Glassfibre Insulated Flat Pair Cable / Wire with Stainless Steel Overbraid (BS)

Image is for colour coding illustration only

Price is per metre - please add required quantity for basket. Only 336 metres left in stock

Glassfibre insulated flat pair construction, conductors laid flat, Glassfibre insulated with Glassfibre jacket, silicone varnished throughout + stainless steel overbraid for added protection and mechanical strength. Good temperature resistance but not suitable where fluids are present.

Specifications

General Description Good temperature range but will not prevent ingress of fluids. Fairly flexible but does not provide good mechanical protection.
Cable Length Priced per metre
Cable Type SSOB PTFE
Core / Strands 14/0.2mm
Outer Colour Black
+ Colour Yellow
- Colour Blue
Insulation Material Glassfibre insulated extension cable with stainless steel overbraiding
Max. Temperature +350°C (short periods up to 400°C)
Min. Temperature -60°C
+ Conductor Iron
- Conductor Constantan
Standards Met BS
Thermocouple Type J
Tolerance Class 2
