High Temperature Miniature Thermocouple Connector MTC-J-M-HTP Plug Type J
Heavy duty plastic body, miniature size to match with flat pin plug. High temperature for use up to 425°C
Specifications
| General Description | Heavy duty plastic body. High temperature for use up to 425°C For R,S & B compensating alloys limit the maximum usable temperature to 260°C |
|---|---|
| Thermocouple Type | Type J High Temp |
| Connector Type | High Temp Plug |
| Connector Size | Miniature |
| Colour | Brown |
| Max. Temperature | 425°C |
| Pins | Flat Pins |
| +Positive Contact | Iron |
| -Negative Contact | Copper Nickel |
| Standards Met | BS EN 50212:1997. RoHS |
3D Animation
3D Animation of High Temperature Miniature Thermocouple Connector From Labfacility
Connectors Colour Chart
International Thermocouple Colour Codes For Connector Bodies. IEC, ANSI and JIS.
3D CAD models provide accurate representations of our thermocouple connectors, allowing you to import them directly into your CAD software to check fit, orientation and clearances before finalising a design.
Whether you're designing a panel, enclosure or complete system, our STEP files help reduce development time, avoid costly design changes, and ensure our connectors integrate smoothly into your application.
